CF850MF-22 CFAIR 850CFM 22 Bar Mobile Compressor for Drilling

CF850MF-22, a portable drilling air compressor, designed by the manufacturer of the leading edge of compressed air solutions, is a drilling unit that is ruggedly designed to meet the needs of the demanding coal mining and water well drilling. CFAIR 850cfm @22bar is powered by famouse CUMMINS engine. Directly connected by coupling, the compressor for drilling can output more air with less energy consumption. Four-wheel drive with large turning radius which is applicable outdoor works under various conditions.

  • Model: CF850MF-22

  • Pull behind compressor for drilling

  • Air delivery: 23.9 m³/min | 850 CFM

  • Pressure: 22 Bar | 319 PSI

  • Compressor diesel engine: FAWDE


Features of CF850MF-22 CFAIR 850CFM 22Bar Mobile Compressor for Drilling

  • ISO 9001 quality assured factory.

  • The compressor for drilling is equipped with CUMMINS engine which means low emission, low fuel consumption; advanced electronic control.

  • customized airend that enables durability and high performance.

  • Four wheels design allows you to tow it easily to the job site.



1)The GHH screw air end achieves an exceptional compression ratio, leading to substantial energy savings and increased efficiency in operation;

2)The Fawde engine offers competitive pricing while maintaining impressive performance

3)The pressure control adopts the pneumatic control component, the power saving capacity adjustment, 0% ~ 100% load control, can adjust the power consumption automatically with the actual use of the amount;

4)High efficient and excellent performance Air Filter and Intake System

5)The use of safe and reliable, with explosion-proof, overload, short circuit, phase break, leakage, anti self starting protection, but also with over temperature automatic shutdown protection and capacity adjustment, pressure valve, safety valve three protection, to prevent drilling air compressor overpressure operation;

6)Flexible moving for the mining blasting environment, the configuration of enhanced twisting axle and traction system, high-load meridian large tires, easy to cope with the mine's harsh road ;

7) Tried and tested airend:   Meticulously engineered and crafted to exacting standards, this premium air end is equipped with oversized bearings and operates at low speeds, guaranteeing superior efficiency and an extended lifespan. It incorporates a high-efficiency two-stage screw air-end with a sizable rotor, ensuring outstanding stability.

8) Alternative Colors:

Blue-Equivalent RAL5017

Green-Equivalent RAL6024

Red-Equivalent RAL3020

Orange-Equivalent RAL2009

Other color available as customer request.

9) Efficiency – a question of quality:We can offer constantly high free air delivery at astonishingly low power consumption. This, together with the perfected oil separation system, results in an exemplary efficiency yield.

10) Abundant heat dissipation system ensures resilience in high-temperature and high-dust environments, resulting in a reduced failure rate.

11)High-capacity fuel tan.


Specs of CF850MF-22 CFAIR 850CFM 22Bar Mobile Air Compressor for Pneumatic Drilling

MODEL
CF830MF-10.5
Air End Type
Rotary Twin Screw, Single stage
Air Outlets
3/4'' x 1 + 2'' x 1
Free Air DeliveryCFM (mm³/min)850 (23.9)
Working Pressurebar (psi)22 (319.0)
Engine Model
China FAWDE
Fuel
Diesel
Emission
China Stage II
Engine Type
6 cylinder, Direct-injection
DisplacementL12.52
L X W X Hmm4325*1900*2340
Weightkg3500

Note: Please feel free to contact us if any more customized requirements!

Application of CF850MF-22 CFAIR 850CFM 22Bar Mobile Air Compressor for Pneumatic Drilling

CF850MF-22 drilling air compressors are characterized by low emission, low fuel consumption and advanced electronic control. They are widely used in coal mining and water well drilling applications. With characteristic of high efficiency, safety and stability and environmentally friendly, mobile diesel compressors for drilling are available for your selection.
